PILZ 312070

PILZ 312070 Product Details

The PILZ 312070 is a head module for the PSSuniversal PLC control system, designed for both failsafe and standard control applications. It achieves Performance Level e (PL e) according to EN ISO 13849-1 and Safety Integrity Level Claim Limit 3 (SIL CL 3) according to IEC 61508. This module features 2 RJ45 ports for SafetyNET p RTFN, Modbus/TCP, Raw UDP, Raw TCP, EtherNet/IP adapter, and PROFINET IO DEVICE communication. It also includes an SD card slot.

Product Parameters

• Product Type: PSSu H PLC1 FS SN SD

• Order Number: 312070

• Control System: PSSuniversal PLC

• Safety: Failsafe and Standard

• Safety Level: PL e (EN ISO 13849-1), SIL CL 3 (IEC 61508)

• Communication Interfaces:

• 2 x RJ45 for SafetyNET p RTFN

• Modbus/TCP

• Raw UDP

• Raw TCP

• EtherNet/IP adapter

• PROFINET IO DEVICE

• Memory:

• 128 MB RAM

• 4 MB user program memory per resource

• 382 kB non-volatile failsafe memory

• 128 kB non-volatile standard memory

• 8 kB Raw UDP

• Connections: Plug-in/detachable screw or spring-loaded terminal connections

• Supply Voltage: 16.8 - 30 V DC (24 V DC nominal)

• Current Consumption:

• 1 A max. continuous current (module supply)

• 10 A max. continuous current (peripheral supply)

• 2 A current load capacity (internal supply)

• Operating Temperature: 0...+60 °C

• Storage Temperature: -25...+70 °C

• Protection Class: IP20

• Dimensions (WxHxD): 130 mm x 125.6 mm x 83.7 mm

• Weight: 0.15 kg (without packaging), 0.407 kg (with packaging)

Product Advantages

• High Safety Level: Certified for PL e and SIL CL 3, ensuring high safety integrity for critical applications.

• Versatile Communication: Supports multiple industrial communication protocols, offering flexibility in network integration.

• Integrated Safety and Standard Control: Combines failsafe and standard control capabilities in one module, reducing hardware and wiring complexity.

• Expandable System: Part of the PSSuniversal system, allowing for easy expansion with up to 64 I/O modules.

• Robust Design: Suitable for industrial environments with an operating temperature range of 0 to 60 °C.

• User-Friendly: Easy programming and configuration with Pilz PAS4000 software.

• High Availability: Extensive diagnostic options contribute to high system uptime.

• SD Card Slot: Enables easy program storage, transfer, and data logging.
